Product Name:J-Hanger for pipe or conduit
   Model:AT-MS-014
   Product Instroduction:

J-Hanger for Pipe or Conduit
Size

Strip width & thickness
Side Bolt
(mm)
Packing Data
Inch
mm
 Dia.
Length
Pcs/CTN
Carton size
Pcs/Pallet
1/2?/DIV>
19x3.0
6.35
44.5
50
26x25x11
7,200
3/4?/DIV>
19x3.0
6.35
50.8
50
26x25x12
6,400
1?/DIV>
19x3.0
6.35
63.5
50
26x25x13
5,600
1-1/4?/DIV>
19x3.0
6.35
69.9
50
26x25x13
5,600
1-1/2?/DIV>
19x3.0
6.35
76.2
50
26x25x15
4,800
2?/DIV>
19x3.0
6.35
88.9
50
26x25x18
4,000
2-1/2?/DIV>
32x3.0
9.50
114.3
25
26x25x20
2,000
3?/DIV>
32x3.0
9.50
127.0
25
37x22x21
1,875
3-1/2?/DIV>
32x2.0
9.50
139.7
20
37x22x24
1,200
4?/DIV>
32x4.5
9.50
152.4
15
37x22x20
900
5?/DIV>
32x4.5
9.50
190.5
15
37x22x23
900
6?/DIV>
44.5x6.3
9.50
215.9
10
35x30x23
360
8?/DIV>
44.5x6.3
9.50
266.7
5
36x26x21
180
Material: Hot rolled Carbon steel strip with Mechanical properties as,
- Yield stress: 235Mpa
- Tension stress: 375~460Mpa
- Elongation ratio: 26%
Finish: Zinc-plated with Max. 8 micro meter plated thickness
Nut: 1/4-20NC for 1/2~2"Size
3/8-16NC for the rest sizes
Thread: ANSI Standard Class II
Place of Original:
Zhejiang, China
Brand Name:
ATLAS or Customer Authorized to specify
Terms of Payment & Shipping
Minimum Order Quantity:
5,000Pieces
Supply Ability:
80,000Pieces per month
Packing Details:
Cartons + Pallets
Delivery Time:
25Working days
Dispatch Port:
Shanghai
Terms of Payment
L/C or T/T
